AI Gateways Hold the Keys—Treat Them Like Tier-0 Infrastructure

Treat an AI gateway as Tier-0 infrastructure because its runtime may hold provider keys, database connections, routing policy and access to downstream tools. Secure it in this order: close and patch exposed surfaces, make administration private, replace shared secrets with scoped identities, restrict runtime privileges and egress, validate model-driven actions, then rehearse detection and credential rotation.

The sequence protects replacement credentials from the original entry path and progressively limits what a later compromise can reach. Require evidence at every stage—deployment records, access tests, policy exports, rejected requests and incident artifacts—so another operator can verify the controls rather than trust an undocumented configuration change.

1. Inventory, close and patch the control plane

Map every component that can administer or execute through the gateway: public inference routes, administrative APIs, web consoles, MCP endpoints, retrieval services, workflow runners, databases, secret stores and container interfaces. Record each component’s owner, deployed version, image digest, authentication method, listening address, enabled routes and upstream dependencies.

Prioritize internet-reachable management surfaces and known exploitable flaws. In Microsoft’s investigation of LiteLLM, RAGFlow and Kestra, the observed paths included gateway-runtime secret harvesting, interception of newly configured provider credentials, workflow-origin shell execution, database access, persistence and cryptomining. The entry paths and affected products differed, but each workload concentrated credentials or execution authority that enabled further abuse.

Deploy fixed versions through the normal release pipeline, rebuild immutable images and remove superseded replicas. Preserve the software inventory, vulnerability scan, change record and image digest; then run an external connectivity test to prove that obsolete endpoints and unintended management listeners are no longer reachable.

2. Make administration private and credentials disposable

Move administrative APIs, dashboards, databases and orchestration consoles onto private network paths behind an identity-aware access layer or tightly controlled VPN. Separate public inference from management routes, authenticate both API and UI access, and limit operator permissions by role and environment. Verify from an untrusted network that no management listener is reachable before proceeding.

Remove master provider keys and database passwords from shared configuration and process environments. Use a managed secret store with workload identity, issue separate credentials per team, service, provider and environment, and restrict each identity to the models, operations and budgets it needs. The distinction between public configuration and protected credentials also matters in hosted development environments, where teams should store keys as secrets rather than ordinary variables.

Test the boundaries instead of reviewing policy names alone. Retain secret-store policy exports, an identity-to-resource matrix, a failed cross-team request and a failed request using a revoked credential. Evidence may identify a secret by version or fingerprint, but it must never expose the value in logs, screenshots or tickets.

3. Reduce runtime reach and deny egress by default

Run the gateway, retrieval service and workflow engine under separate service accounts and trust boundaries. Give each service access only to required database objects and internal endpoints; remove host-path mounts, privileged capabilities, cloud metadata access and container-runtime sockets unless a documented function requires them.

Apply deny-by-default outbound policy to each workload. Allow only required model-provider APIs, internal services, DNS resolvers and observability destinations, preferably through an FQDN-aware filtering layer; block direct raw-IP connections and unexpected ports. Test that an approved provider request succeeds while attempts to reach an unlisted domain, a raw IP address and the metadata endpoint fail.

The OWASP Secure AI Model Ops guidance supports this containment approach with least-privilege workloads, separated trust boundaries, scoped serving credentials, resource limits, restricted network access for untrusted jobs and disabled access to host paths, container sockets and metadata services. Keep the successful and rejected network tests with the effective workload policy, not only the intended policy in source control.

4. Validate prompts, outputs and tool calls server-side

Network controls do not make model output authoritative. Construct prompts in a trusted server-side component, keep instructions separate from user or retrieved content, and subject documents, tool results, stored memory and previous completions to the same controls as direct input.

Before execution, parse model output into an allowlisted structure and validate required fields, types, ranges, permitted values, maximum lengths and unexpected properties. Authorize the validated operation against the current user or workload identity, use parameterized database operations, expose only task-specific tools and require human approval for sensitive or irreversible actions.

The OWASP LLMSVS 2.0 requirements cover server-side prompt construction, secure provider credentials, JSON schema validation, untrusted completions, validation of tool parameters, task-scoped tools, restricted agent egress and minimum-scope third-party tokens. Preserve negative tests demonstrating rejection of malformed fields, extra properties, unauthorized tool calls, cross-tenant retrieval and instructions injected through retrieved content.

5. Correlate the attack chain and rehearse rotation

Collect control-plane audit events, authentication decisions, secret-store access, provider usage, DNS queries, outbound connections, child processes, filesystem changes and database activity. Redact credentials and sensitive prompt content at collection time, retain a stable request or trace identifier, and correlate related signals rather than alerting on each event in isolation.

High-value sequences include an application process spawning a shell or interpreter, reading process environments, changing startup files or authorized keys, accessing a container socket, executing from a temporary directory and making an unusual outbound connection. Establish per-team baselines for requests, tokens, cost, latency, retries, tool calls and concurrency so operational changes can be distinguished from suspicious deviations.

The incident runbook should first isolate affected workloads and block suspicious egress, then capture volatile evidence and identify every credential the runtime could reach. From a clean administrative path, rotate gateway credentials, provider keys, database passwords, service-account tokens, webhook secrets and downstream tool tokens; revoke old versions, invalidate sessions and rebuild affected workloads from trusted artifacts.

Return the gateway to service only after the original exposure is closed, replacement credentials have narrower scopes and the monitoring path can detect the behaviors exercised during the rehearsal. The final evidence bundle should contain the incident timeline, reachable-secret inventory, revocation confirmations, provider-usage review, clean image digests, persistence checks and fresh access and network-policy test results.
